Product imageEKITENGINE S380 L4P1T
Huawei eKitEngine S380-L4P1T 4-Port PoE Gateway
Model: EKITENGINE S380 L4P1T
Huawei S380-L4P1T multi-service gateway for up to 200 users, with one GE WAN, four GE PoE LAN ports, 50W PoE and 8Gbps switching.
HuaweiBrand
EKITENGINE S380 L4P1TModel
NetworksCategory
Key information
Maximum users
200
Switching capacity
8Gbps
Packet forwarding
Upload 300Kpps — download 420Kpps
Egress bandwidth
1Gbps
WAN ports
1 × GE
LAN ports
4 × GE with PoE
Available technical specifications
| Maximum users | 200 |
|---|---|
| Switching capacity | 8Gbps |
| Packet forwarding | Upload 300Kpps — download 420Kpps |
| Egress bandwidth | 1Gbps |
| WAN ports | 1 × GE |
| LAN ports | 4 × GE with PoE |
| PoE budget | 50W |
| Dimensions | 35 × 210 × 130mm |
Use and planning
- Small offices and shops
- Clinics and branch sites
- Small camera and AP networks
- Sites needing one integrated appliance
Before confirming the order
The exact version, compatibility and quantity are confirmed in the quotation before supply.
Service scope
- Confirming model and quantity before supply.
- Installation, configuration and testing according to the quotation scope.
- Documented handover and user guidance when included.
Verification before supply
- Review the version and region before ordering.
- Confirm compatibility with existing equipment.
- Approve final specifications in the quotation.
Warranty and support
Warranty duration, regional version and installation scope are confirmed in the final quotation, with configuration, testing and handover provided according to the project scope.
Related products
Frequently asked questions
How many PoE ports does S380-L4P1T provide?
It has four Gigabit LAN ports with PoE within a total 50W budget.
How many users does it support?
Huawei lists a maximum of 200 users.
Can it replace a separate router and switch?
It combines gateway and PoE switching functions, but suitability depends on bandwidth and required services.
Is EKITENGINE S380 L4P1T right for your project?
Send the site requirements and required quantity so we can review compatibility and equipment before preparing the quotation.
